XL6009 Adjustable DC-DC Step Up Voltage Regulator Module Boost Converter 4A

In stock
B-02-01-02
DSN6009 4A is a high-performance step-up switching current (BOOST) module. The module uses the second generation of high-frequency switching technology XL6009E1 core chip performance than the first...
$2.63
$2.63
  customers are viewing this product

DSN6009 4A is a high-performance step-up switching current (BOOST) module. The module uses the second generation of high-frequency switching technology XL6009E1 core chip performance than the first generation technology LM2577. XL6009 boost module at a lower cost, superior performance, LM2577 module is about to be eliminated.
● Wide input voltage 3V ~ 32V, optimum operating voltage range is 5 ~ 32V;
● Wide Output voltage 5V ~ 35V;
● Built-4A efficient MOSFET switches enable efficiency up to 94%; (LM2577 current is 3A)
● high switching frequency 400KHz, can use a small-capacity filter capacitors that can achieve very good results, the ripple smaller and smaller. (LM2577 frequency only 50KHz)

Technical parameters:
DSN6009 boost module
Model Specification
Module Properties Non-isolated boost (BOOST)
Rectification Non-Synchronous Rectification
Input Range 3V ~ 32V
Output Range 5V ~ 35V
Input Current 4A (max), no-load 18mA (5V input, 8V output, no-load is less than 18mA. Higher the voltage, the greater the load current.)
Conversion efficiency <94% (greater the pressure, the lower the efficiency)
Switching frequency 400KHz
Output Ripple 50mV (the higher the voltage, the greater the current, the greater the ripple)
Load Regulation ± 0.5%
Voltage Regulation ± 0.5%
Operating Temperature -40 ℃ ~ +85 ℃
Dimensions
43mm * 21mm * 14mm (L * W * H)


Package Included:
1 x XL6009 DC-DC Boost Converter Adjustable Step-Up Power Module Replace LM2577
